4.9G 5.8G 2.5W FPV VTX BEASTFPV VTX 64CH Image Transmission Drone Accessories

1.Video transmitter parameters

2.Functional diagram

3. Video transmitter power indicator:

5.Power adjustment:

This video transmitter has 5 power levels: 25/400/800/1500/2500 mW. To adjust the power, press and hold the button for 6 seconds, after which the video transmitter will go into the power adjustment mode. The power is selected in order by pressing the button once. The number of flashes (blinks) of the red indicator R1 will correspond to the selected power: 1 blink - 25 mW, 2 blinks - 400 mW, etc. (pay attention to: “3. Video transmitter power indicator”). To save the selected power, you must wait 5 seconds, after selecting the power - the video transmitter will save the value. (When adjusting the power of the video transmitter - the red power indicator R1 blinks, and the other indicators go out).
